Description
Pneumatic solenoid valve 4V230-06 Double coil
5/3 way control valve with Plug type red LED light
Voltage: 110V AC ,220V AC ,380V AC ,24V AC ,12V DC ,24V DC .
1.Specification
|
Product Name |
Solenoid Valve |
|
Model No. |
4V230-06 |
|
Fluid |
40 Micron Filtered Air |
|
Operation Type |
Internal Piloted |
|
Port Size |
G1/8",G1/4" |
|
Working Pressure |
0.15~0.8MPa |
|
Type |
5 Way 3 Position |
|
Power Consumption |
DC24V,DC12VDC,220VAC,110VAC |
|
Temperature |
60°C |
|
Maxi. Withstand Pressure |
1MPa |
|
Threaded Port Size(Approx) |
|
|
Overall Size(Approx) |
15.5 x 5.5 x 2.2cm / 6.1" x 2.2" x 0.9" (L*W*H) |
|
Color |
White, Black |
|
Net Weight |
400g |
|
Package Content |
1 x Solenoid Valve |
Description:
-
With solenoid operated for control appropriate flow and direction, provide great performance.
-
Stury body have a long lifespan, perfect for electrically driven pneumatic power control.
-
Two Coil 2 position solenoid valve.
