Battery DC Circuit Breaker MCB 80A 100A 125A 12V 24V 48V 72V 96V 240V B Curve Overload Short Circuit DC Disconnect Switch

● Rated voltage: DC 12V, 24V, 36V, 48V, 72V, 96V,100V 120V ,220Vetc
● Rated current: 80A,100A,125A
● Breaking capacity: 6KA
● Trip characteristics: B (3-5)In
● Polar number: 1P (1 Pole), 2P (1 Poles), 1P+1P (Dual power switch with lock function), 2P+2P (Dual power switch with lock function)
● Current limit level: 3
● Quick closing
● Electrical life: 10,000 times
● Mechanical life: 20,000 times
● Operating ambient temperature:-30 °C to +70 °C
● Conform to standard: GB10963/ IEC60898
● Warraty: 18th Month
DC 12V~240V circuit breakers for electric vehicles (air switches for electric vehicles, circuit breakers for battery vehicles), MINI circuit breakers for electric motorcycles, with overload and short circuit protection, at the same time It can also be used for on-off electrical devices and electric vehicle lighting circuits that are not frequent under normal conditions. DC circuit breakers comply with GB10963.1 and IEC60898-1 standards.
