Description
Parameters
HP827 is an adjustable output power RF signal generator instrument
1. Signal range 28~5400MHz
Pulse signal duty cycle
2. Signal amplitude -10~0DBm
3. Scanning time range: 10ms~10000ms
4. Adjustable attenuation value from 0 to -31DB
Step decay value 0.5
6. Working voltage 7~9VDC
7. Working current<350mA
8. Size 61 * 45 * 20mm, length X width X height
9. Weight 50g
