ONCCY 8P DC Solar Isolator Switch,1600V 1000V DC Isolator Switch, Single Hole Mounting, 30A 40A 50A Positive contact

Description

• Non-polarity DC lsolator Switch

• Modular design, optional 2-10 levels.

• Reverse contact optional.

• Single Hole Mounting.

• Dynamic sealing design and word class sealing materials guarantee an lP66 protection rate.

• Dc 1600V insulation voltage design,passd ECEN60947-3:2009+A1+A2, AS60947.3, UL508,.GB/T14048.3 test, with TUV, CE,CB, SAA, UL, CCC certifications.

Technical Data

Rated impulse withstand voltage Uimp: 8000V

Rated short-time withstand current (1 s)lcw: 780A

Rated short-time making capacity lcm: 1200A

Distance of contacts (per pole): 8mm

Operation temperature: -40°C to +85°C

Store temperature : -40°C to +85°C

Pollution degree: 3

Overvoltage category: II

Dimensions(MM)

N=Pole Number
