Oil-Free Air Compressor Accessories Packing Leather Cylinder Mute Compression Air Pump Vacuum Piston Ring Tile

Oil-free air compressor accessories imported packing leather cylinder high-end steel sleeve mute compression air pump vacuum piston ring Tile
Packing: 1PCs OPP bag
Material: cast aluminum
Driving Mode: Electric

Packing leather precautions during installation:
1: The Bump below the pressure plate is aligned with the groove on the connecting rod
2: The screw below the valve plate is aligned with the groove on the pressure plate

Other skills reference:
1: the air on the machine is slow and there is no abnormal sound. Most of them are packing leather and have already started to wear
2: the air on the machine is slow and accompanied by abnormal sound, most of which is that packing leather has been seriously worn and the cylinder may also be worn.
Suggestions:
Packing leather if the cylinder is seriously worn, replace it as much as possible. If the cylinder has been worn, it will be easily damaged if the packing leather is changed, don’t buy packing leather cylinder externally. It will put packing leather into the cylinder after molding to prevent packing leather from rebounding until it cannot be installed after receiving the goods.
Note: The new packing leather should be heated by a hot hair dryer about 60 degrees (5 minutes) before being inserted into the cylinder.
Note: the fully formed packing leather needs to be purchased together with the cylinder at present, (one cylinder can only cover one packing leather), and purchased separately packing leather is currently shipped.
Still 30 degrees forming packing leather
