Description
MYAMi MY-K3050E laboratory variable 1500W 32v 50a bench switching DC power supply
Feature:
(1) Voltage and current can be preset;
(2) Voltage, current, power, equivalent resistance 4 Windows 4 high precision display at the same time;
(3) over voltage, over current, over power, over temperature, cornet 5 double protection;
(4) ON/OFF output on-off switch;
(5) 2 high quality coded switches, control voltage and current and thickness adjustment;
(6) SENSE compensation interface is optional at the back;
(7) It is equipped with communication serial port RS232 at the back, and the upper computer software can read and control the output on/off, voltage value and current value;
(2) Voltage, current, power, equivalent resistance 4 Windows 4 high precision display at the same time;
(3) over voltage, over current, over power, over temperature, cornet 5 double protection;
(4) ON/OFF output on-off switch;
(5) 2 high quality coded switches, control voltage and current and thickness adjustment;
(6) SENSE compensation interface is optional at the back;
(7) It is equipped with communication serial port RS232 at the back, and the upper computer software can read and control the output on/off, voltage value and current value;
Rated DC output (0℃～～40℃)
Voltage stability: ≤2%
Current stability: ≤0.5%
Load stability: ≤0.5%
Ripple and noise: ≤1% (RMS)
Voltage resolution: <100V: 10mV ≥100V: 100mV
Current resolution: <100V: 10mV ≥100V: 100mV
Power resolution: <10W: 1mW ≥10W: 10mW ≥100W: 0.1W ≥1000W: 1W
Display resolution of load equivalent resistance: <10R: 1mR ≥10R: 10mR ≥100R: 0.1R ≥1000R: 1R
Output voltage preset accuracy: 0.1V
Output constant current preset accuracy: 0.1A
Altitude:≤2000m
Relative humidity: <80%
Ambient temperature: 5℃~ 40℃
Ambient temperature: -20~ 80℃
Relative humidity: ≤80%
Power input: A220V±10%, 50Hz (or A110V input or A100V/220V manual switching)
Reminder: 110V input or 220V input can be fixed within 900W; 110V input is not supported above 1000W
Accessories: manual, power cord, certificate
