Description
High Frequency 10mm Miniature Solenoid Valve SMC Type 2 Position 3 Way N.C. Pneumatic Air Valve Knitting Machine Socks Machine
Welcome to the store. Any questions about the product you can feel free to contact me, I will answer for you.
Difference between regular and large flow models:
Regular L/M type diameter: inlet 0.75MM outlet 1.0MM
Large flow L / M type diameter: inlet 1.0MM outflow 1.2MM
————————————————————————————————————————————————————————————
Name:Miniature solenoid valve
Model:T10 valve series
Commodity type:Two-position three normally closed 3/2 N.C.
Working medium:compressed air, inert gas
Working Pressure:0~7bar
Port diameter:Ф0.75mm(P port)/Ф1.0mm(R port)
Flow rate at 6bar(Δp=1bar):16 L/min(P1→P2)
23 L/min(P2→P3)
Standard voltage:DC24V DC12V DC6V DC3V
Lubrication:Not required
Response time: within 15ms
Maximum operating frequency: 30Hz
Measured service life: more than 50 million times
Welcome to the store. Any questions about the product you can feel free to contact me, I will answer for you.
Difference between regular and large flow models:
Regular L/M type diameter: inlet 0.75MM outlet 1.0MM
Large flow L / M type diameter: inlet 1.0MM outflow 1.2MM
————————————————————————————————————————————————————————————
Name:Miniature solenoid valve
Model:T10 valve series
Commodity type:Two-position three normally closed 3/2 N.C.
Working medium:compressed air, inert gas
Working Pressure:0~7bar
Port diameter:Ф0.75mm(P port)/Ф1.0mm(R port)
Flow rate at 6bar(Δp=1bar):16 L/min(P1→P2)
23 L/min(P2→P3)
Standard voltage:DC24V DC12V DC6V DC3V
Lubrication:Not required
Response time: within 15ms
Maximum operating frequency: 30Hz
Measured service life: more than 50 million times
